CRL GEN037CH Wall To Glass Shower Door Hinge

GEN037CH Geneva Shower door hinges from CRL

The most popular selling door hinge for bespoke and custom shower glass. The Geneva hinge is perfect for most shower applications where a door is required, the hinge itself has 4 screw mount positions to equally spread the load from the glass into the wall or fixing area.

Once mounted the hinge will allow the door to both swing inwards or outwards and hold at 90 degrees.

Hinge specifications:

  Glass Thickness:  8 mm to 12 mm Toughened Safety Glass

       Hinge Swings:  90 Degree in and 90 Degree Out

       Closing Type:  Self-Centring when within 15 Degree of Closed Position.

           Deduction:  8mm from glass width.

          Back-plate:  Central back-plate

         Two hinges:  Up to 36 kg, with a max door width of 711 mm

       Three hinges:  Up to 54 kg, with a max door width of 813 mm

Glass Fabrication:  Cut-Out Required in Glass, See Template in product images.

             Includes:  Gaskets, Screws, and Glass Fabrication Dimensions

       Construction:  Solid brass with all moving parts (pins and springs) in stainless steel.
